Category: Uncategorized

Jun 17

Failure analysis

This video shows the 3D morphology of a crack in steel. This is used for failure analysis in various industries and for all kinds of products and materials. Such information (as crack morphology in 3D) is useful for safety investigations, lifetime prediction, failure root cause analysis for future prevention, and also for legal disputes. Video …

Continue reading

Jun 03

Biomedical CT scans

Any medical CT data can be processed, visualized and analyzed in detail at our facility. Got a medical CT data set and need something MORE? No problem, we do it. All we need is the DICOM or image stack with XYZ slice and pixel spacing. We also handle 3D data from serial block face imaging, …

Continue reading

Jun 02

How to crop a volume

CT data is big. Sometimes you need to share data more easily, for example using file transfer services but 10 Gb just doesnt work. Here is a video showing how to select a region of interest and export it to a new volume of less than 2Gb, with a VGL file associated with it so …

Continue reading

Jun 02

Level 3 lockdown

Great news – we have opened under strict level 3 conditions from 1 June 2020. We are open for work under the following rules: From June 1st, clients are advised to use the drop-off booking option to submit samples for scanning or data for analysis https://www.supersaas.com/schedule/CAF_Booking_systems/CT_Facility Samples and data drives will be delivered at scheduled …

Continue reading

Jan 24

Reverse engineering a drone blade

This examples shows a microCT scan of a drone blade – with the creation of a volume mesh – useful for reverse engineering or simulation. Enjoy the video Drone blade smaller Here is the volume mesh file if interested: https://www.thingiverse.com/thing:4129237

Oct 30

Halloween CT scan

If embedded version does not work here is a link to the video: halloween Here an image if you have trouble with the video:

Sep 04

Foam structure analysis

In this example a nanoCT scan of a 3 mm section of rigid foam is used to demonstrate the analysis of connected pore spaces. For more technical details please contact us, the images speak “volumes” by themselves:

Sep 03

NanoCT of woven material

This example shows a small section of material scanned using nanoCT and analyzed for fibre thickness and angular distribution Very short video of the CT slices: fibres

Sep 03

NanoCT of cardboard

One application of nanoCT scanning is to measure coating thickness of paint coatings for example. In this case a cardboard packaging material has its paint coating analyzed with a colourmap showing the thickness distribution.

Sep 03

Flower for Womens day

It was women’s day recently in South Africa so we scanned a flower and made a digital colourful mesh, which you can open in any CAD program or even windows10 can open it in 3D. Find the files on thingiverse here: https://www.thingiverse.com/thing:3843542 Also see the video here and send someone a digital flower : FLOWER
